Features of bucket sand washer
1.In the bucket sand washer, the bearing device with reasonable structure and impeller drive is isolated from water and water materials to avoid damage of bearing due to soaking, the corrosions of sand and pollutants.
2.The bucket sand washer has little loss of medium fine sand and stone powder.
3.The bucket sand washer has almost no wearing parts except the screen cloth.
4. The bucket sand washer is in long service life and convenient maintenance.
5. The bucket sand washer can save water.
Working principle of bucket sand washer
The sand and gravel enter the washing tank of bucket sand washer by feeding trough, roll under the drive of the impellers, and grind each other, remove the impurities covering the surface of the sand, and destroy the moisture layer covering the sand at the same time, so as to facilitate dewatering. At the same time, water is added to form strong water flow, and impurities and foreign materials with small gravity are taken away, and discharged from the overflow outlet of bucket sand washer to complete the cleaning effect. The clean sand is carried away by the blade, and finally the sand is poured into the discharge trough from the rotating impellers to finish the cleaning of the sand.
Specification of bucket sand washer
Model | Wheel Diameter (mm) | Capacity (t/h) | Power (kw) | Wheel rotary speed (r/min) | Input Size (mm) | Weight (t) | Dimensions (mm) |
XS2600 | 2600 | 20-50 | 5.5 | 2.5 | ≤10 | 2.5 | 3515×2070×2672 |
XS2800 | 2800 | 50-100 | 7.5 | 1.2 | ≤10 | 4.1 | 3900×3300×2990 |
XS3200 | 3200 | 80-120 | 11 | 1 | ≤10 | 7.3 | 3965×4440×3410 |
XS3600 | 3600 | 120-180 | 15 | 1 | ≤10 | 9.5 | 4355×4505×3810 |
Case 1：China Nantong XS3200 Wheel type sand washer
This equipment is used in the sea sand purification production line, to clean and wash the quartz sand after the gravity separation unit, to remove the impurities contained in the product, and the impurity removal effect is obvious.
Case 2：China Jiangsu XS2800 Wheel type sand washer
The customer purchased three sets of XS2800 Wheel type sand washer to thoroughly clean and wash the quartz sand scrubbed by attrition scrubber.
According to my years of production experience in quartz sand, I believe that the stability of equipment is the first, the stability of equipment is an important reflection of reliable quality of equipment, but also an important guarantee for the normal operation of my production line. The stability of Sinonine equipment is the best in the industry, which has also been verified in the actual use. Based on the trust in the stability of Sinonine equipment, I have purchased a lot of Wheel type sand washers from Sinonine. These devices have a low failure rate and are convenient to use and maintain, which have provided a lot of help to my project.
