Gyratory vibrating Screen characteristic
1.The gyratory vibrating Screen can screen a wide range of particle sizes and different size range specifications.
2.gyratory vibrating screen can be configured with multi-layer screen, so the processing capacity is large.
3.gyratory vibrating screen is with large exciting force, screening efficiency is high.
Gyratory vibrating Screen work principle
The sgyratory vibrating screen is also called reciprocating screen, the vibration force generated by the motor drive, the vibration force around the fixed axis, is the inertia force with a certain change in direction, and its essence is the reciprocating inertia force formed by the rotation of the eccentric wheel around the fixed axis. The inclination Angle between the screen body and the horizontal surface is 4.5°-5.5°, so that the material smaller than the mesh can quickly reach the lower screen surface through the screen. The material is continuously screened by multiple layers, classified from multiple discharge ports, and through a unique design, the materials of same mesh number are gathered in one place at the discharge port to complete the screening work.
Technical parameters of gyratory vibrating Screen
Model | Mesh size (mm) | Single layer Mesh area (m2) | Power (kw) | Install angle (°) | Frequency | Stroke (mm) | Layer |
ZS1036 | 1000x3600 | 3 | 3 | 5 | 180-260 | 25-60 | 1-9 |
ZS1236 | 1200x3600 | 4 | 5.5 | 5 | 180-260 | 25-60 | 1-9 |
ZS1536 | 1500x3600 | 5 | 7.5 | 5 | 180-260 | 25-60 | 1-9 |
ZS2040 | 2000x4000 | 8 | 11 | 5 | 180-260 | 25-60 | 1-9 |
