Features of sand making machine
1.Sand making machine is simple and reasonable structure, low cost.
2.Sand making machine is high crushing ratio, energy saving.
3.Sand making machine is fine crush and grind.
4.Sand making machine is permit moisture content of raw material up to about 8%.
5.Sand making machine is suitable for crushing hard material.
6.Sand making machine has excellent shape of final product.
7.Sand making machine is small abrasion, easy maintenance.
8.Noise when sand making machine working is below 75dB.
Working principle of sand making machine
The materials fall into impeller with high-speed rotation vertically. On the force of high-speed centrifugal, the materials strike to the other part of material in a high speed. After mutual impacting, the materials will strike and rub between the impeller and the casing and then be discharged straight from the lower portion to form a closed multiple cycles. Final product is controlled by screening equipment to meet the requirement.
Specification of sand making machine
Model | VSI-7611 | VSI-8518 | VSI-9526 | VSI-1140 | VSI-1145 | |
Capacity (th) | Center and Ring Feeding | 120-180 | 200-260 | 300-380 | 450-520 | 500-640 |
Center Feeding | 60-90 | 100-130 | 150-190 | 225-260 | 250-360 | |
Max.Feeding Size (mm) | Soft Material | <30 | <35 | <40 | <40 | <40 |
Hard Material | <25 | <30 | <35 | <35 | <35 | |
Rotation Speed (r/min) | 1700-1890 | 1520-1690 | 1360-1510 | 1180-1310 | 1100-1310 | |
Power for Double Motor (Kw) | 110-150 | 180-220 | 264-320 | 400-440 | 400-440 | |
Overall Dimension (mm) | 3700×2150×2100 | 4140×2280×2425 | 4560×2447×2778 | 5000×2700×3300 | 5100×2790×3320 | |
Power Source | 380V, 50Hz | |||||
Lubrication Hydraulic Pressure Station | Power for Double Oil Pump (KW) | 2×0.31 | ||||
Safety | The double oil pumps ensure the supply of the oil; Stop working without oil or hydraulic pressure;Temperature falls when the water cools;Start the motor by heating it in winter. | |||||
Overall Dimension (mm) | 820×520×1270 | |||||
Power for Oil Box Heater (kw) | 2 | |||||
Case 1：Chile VSI 8518 sand making machine
According g to our Suggestions, the customer employed VSI 8518 crusher as the main equipment for artificial sand making, and produces quartz sand products that fully meet the requirements for construction and building use, which are recognized by the customer.
Case 2：Brazil 4VSI9526 sand making machine
The customer purchased four sets of JZC350 VSI9526 crushers from our company in 2018, used in a dry artificial quartz sand production line with a large capacity, a closed circuit was made by this crusher and a vibrating screen for fine crushing, and the quartz sand yield reached 55%, which is the leading level in this area
Sinonine's design is very detailed and takes full account of the ease of use and maintenance. Due to its strong manufacturing capacity, this sand making equipment adopts advanced manufacturing technology, which is not only cheap in cost but also highly efficient in use. In the process of communicating with Sinonine, I realized their thoughtful service, and many of their Suggestions were in line with the engineering practice, which was of great help to me. In addition, Sinonine's non-standard design is very powerful. It can design and manufacture many non-standard equipment according to my needs, which many companies cannot do.
